Battery Load Bank

It is significant to check battery capacity in a regular basis. And the only reliable way to measure the battery capacity is to carry out a discharge test which is a must-to-do job to energize standby batteries and extend their life span. PITE 3980 series DC load banks feature unique design and excellent performance that will facilitate your work for battery maintenance. It covers different types of batteries (1.2V, 2V, 6V and 12V). With different models, it has wide range of discharging like 24V, 48V, 110V, 220V and 380V. With optional DAC, discharging values of each cell could be viewed on the LCD display and computer simultaneously by using the PITE DataView software.

Design features
Product function
Technical parameter

Small weight, portable unit, convenient for onsite test

Customized models for smart selection of users from different industries

Optional wireless DAC enables its PC monitoring during measurement

It sets 4 conditions for auto shut-down of discharge: discharge time, discharge capacity, string voltage and cell voltage.

Continued discharge available when previous discharge is stop abnormally

Parallel connection of two units for higher discharge current

With DAC, it has real-time display of voltage for each cell

Can work with other load banks for assistant discharge

Can monitor the measurement of other load banks or battery chargers

Accurate data measurement with vivid waveforms

Auto sorting for lag-out batteries during discharging

Safe circuits avoids damage to battery when testing

Direct USB drive for convenient data transfer to PC

Powerful management software for data analyzing and report printing

Thermal cut-off and automatic overload protection

Mains Voltage	1). AC 220V/110V, 50/60Hz; 2). DC (optional for some models)
Discharging Current	Accuracy: 1% Resolution: 0.1A or 0.5%
Discharge voltage range	48V: 10-55.2V 110V*: 10V-132V 220V: 10-264V 380V: 10-437V
Voltage Accuracy	0.5%
Sampling Interval	5s –1min
LCD Display	128*64 pixel
Temperature	0℃～40℃
Humidity	5%～90% Relative humidity
Safety standard	CE market, EMC standard
Dimension & Weight (main unit)*	400177280 mm (Size: S, 11kg) 520202355 mm (Size: M, 16kg) 555225435 mm (Size: L, 21kg) 603400740 mm (Size: XL, 43kg) 740400730 mm (Size: XXL, 52kg)

* 1). Dimension and weight depend on different models. Please refer to brochure of each model for details.
* 2). In some countries, 110V is replaced by 120V (10-144V). And 220V is replaced by 240V (10V-288V).
